Existing steam piping routes to and from an existing heat exchanger past column 8-C with a minimum clearance of five feet horizontally and approximately seven feet vertically. A column-mounted fire extinguisher is designated for removal due to obstruction by the piping layout. The photograph is labeled as photo B on drawing D-13-103 near shear wall 3 B-C.
5 FT EXISTING STEAM PIPING TO/FROM EXISTING HEAT EXCHANGER --------------------- (MIN) I COLUMN 8-C L \ V REMOVE COLUMN MOUNTED FIRE EXTINGUISHER (OBSTRUCTED) +i ll o Ll N. i i 1 •1- . i Of K-Va DISTANCE FROM VERTICAL PIPING TO CONNECTION WITH HEAT EXCHANGER IS APPROXIMATELY 7-FT. D-13-103 NO SCALE PHOTO B SHEAR WALL 3 B-C
