C-2BEPC — Detail

Civil · C-2BEPC

Detail

Units: imperial
Sheet: C6X
Discipline: Civil

Materials

Elements

Columns Connections / Plates Decks

Connections

Deck Attachment HSS Connection Welded Connection

Text on the drawing

NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR COLUMN W, HSS, OR BOXED COLUMN TYPICAL L3x3x3/16 TYPICAL 16GA CLOSURE PL DETAIL DETAIL B C TYP 3" 3/16 TYP

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
