The detail illustrates a steel column (wide flange, hollow structural section, or boxed column) with typical L3x3x3/16 angles attached via typical 3/16 welds. A typical 16-gauge closure plate is included in the assembly. Notes specify that deck support angles are to be supplied by the structural steel contractor.
NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR COLUMN W, HSS, OR BOXED COLUMN TYPICAL L3x3x3/16 TYPICAL 16GA CLOSURE PL DETAIL DETAIL B C TYP 3" 3/16 TYP
