Civil · C-26MT4

U-102 Elevation N

Scale: SCALE: 1/2" = 1'-0"
Units: imperial
Sheet: C5
Discipline: Civil

Elements

Millwork / Casework

Text on the drawing

EQ EQ 1'-6" 8'-0" 22.05 12.02 10.07 22.01 09.26 3'-0" 26.36 2'-6" 3'-0" 6" 2'-10" P-02 PB-02 PT-07
