Flexible conduit routes wiring from hoods FH1, FH2 and exhaust fans EF1, EF2 into the Airvantage system control DCV control cabinet at terminal J6. Additional references direct the installer to the DCV control wiring diagram for further details.
REFER TO DCV CONTROL WIRING DIAGRAM FOR DETAILS DCV CONTROL CABINET J6 HOODS FH1 FH2 EF1 EF2 S1 C1 FLEX CONDUIT AIRVANTAGE SYSTEM CONTROL
