Concrete tilt-up wall panels meet at an outside corner featuring a one-half inch joint width and three-quarter inch typical chamfers on the exterior edges. A continuous backer rod and sealant are installed at each face running from the footing to the top of the panel and across the joint.
CONC. TILT- UP WALL PANEL BACKER ROD AT EACH FACE WITH CONTINUOUS SEALANT FROM FOOTING TO TOP OF PANEL AND ACROSS 1/2" PANEL JOINT TYPICAL 1/2" 3/4" CHAMFER TYPICAL
