Suspended wood planks continue on either side of a light fixture junction box supported by manufacturer-specified hanger wires. Acoustic insulation sits above the ceiling assembly. The junction box size and opening requirements are coordinated with the manufacturer. Ceiling height is referenced per the reflected ceiling plan.
CEILING HT SEE RCP 09 54 26 HANGER WIRE PER MANUFACTURER 09 54 26 ACOUSTIC INSULATION 09 54 26 SUSPENDED WOOD CEILING DIV 26 LIGHT FIXTURE DIV 26 J-BOX, CONFIRM SIZE AND OPENING REQ WITH MANUFACTURER WOOD PLANK CONTINUES, EITHER SIDE OF FIXTURE
