A field-fabricated pipe flashing assembly occurs at a roof edge with a concrete tilt-up wall panel and steel deck. Single-ply TPO roofing membrane extends across rigid insulation over the steel deck, terminating at the wall. A continuous cleat fastened at sixteen inches on center secures the assembly. Sealant is applied at the perimeter, with fasteners spaced at twenty-four inches on center on both sides.
SEAL TPO SINGLE PLY ROOFING FASTENED @ 24" O.C. BOTH SIDES RIGID INSULATION A A SLOPED INWARD CONTINUOUS CLEAT FASTENED @ 16" O.C. SECTION AA STEEL DECK (SEE STRUCT.) CONCRETE TILT- UP PANEL 1" = 1'-0" A511 B2 FIELD FABRICATED PIPE FLASHING1 ©
