This architectural detail shows a hollow metal door head frame set within a metal stud partition. The partition is framed with metal studs and metal runner tracks, faced with gypsum board on both sides, and filled with a sound attenuation blanket. The welded steel door frame is detailed with clearance dimensions of 1/2 inch, 1 1/2 inches, and 5/8 inch. A scheduled ceiling aligns with the partition construction as referenced on the reflected ceiling plan. The door itself is hung within the welded steel frame.
AS SCHEDULED GYPSUM BOARD METAL STUD METAL RUNNER TRACK SCHEDULED CEILING, SEE RCP SOUND ATTENUATION BLANKET 1/2" 5/8" 1 1/2" PARTITION TYPE COORDINATE WITH EQ EQ SCHEDULED DOOR STEEL FRAME (WELDED)
