A-ZWCJC — 4" Rigid Roof Insulation

Architectural · A-ZWCJC

4" Rigid Roof Insulation

Units: imperial
Sheet: A6.01
Discipline: Architectural

Materials

Membrane / Roofing Metal (misc.)Timber / Wood

Elements

Decks Insulation Roofs Waterproofing / Flashing

Text on the drawing

R4 METAL ROOFING WRB COVERBOARD 4" RIGID ROOF INSULATION SHEATHING PER STRUCTURAL LAMINATED WOOD DECKING (ATRIUM ROOF)
