Waterproof flashing and membrane integration for a screen wall support or kicker penetrating a roof assembly. An adhered membrane flashing extends up the rigid penetration with a minimum height of eight inches above the roof surface, secured at the top with a stainless steel drawband and silicone sealant. Additional silicone sealant is applied between the penetration and the flashing membrane. An air and vapor barrier is flashed and sealed to the penetration at the roof level, referencing detail one for the underlying roofing assembly.
REFER TO DETAIL 1 FOR ROOFING ASSEMBLY (TYPICAL) INSTALL SILICONE SEALANT BETWEEN PENETRATION AND FLASHING MEMBRANE S.S. DRAWBAND SILICONE SEALANT SCREEN WALL SUPPORT / KICKER NOTES: 1. PENETRATIONS SHOULD HAVE A MIN. 12" CLEARANCE ON ALL SIDES FROM WALLS, CURBS AND OTHER PROJECTIONS. 2. PENETRATIONS SHOULD BE RIGID, ROUND OR SQUARE TUBE AND EXTEND PERPENDICULAR FROM THE SURFACE OF THE ROOF. 3. SCREEN WALL SUPPORT / KICKER TO BE COMPLETELY WATERTIGHT ABOVE ROOF MEMBRANE FLASHING. 4. REFER TO STRUCTURAL DRAWINGS FOR ATTACHMENT AND LOCATION OF SCREEN WALL SUPPORTS / KICKERS. MINIMUM 8" AIR / VAPOR BARRIER, FLASHED AND SEALED TO PENETRATION (TYPICAL) ADHERED MEMBRANE FLASHING
