Concrete filled metal pan treads frame into an HSS stair stringer with typical dimensions including eleven-inch treads and four-inch risers. The stair assembly interfaces with a concrete floor slab treated with a concrete sealer. The structural framing includes a wide-flange beam connection adjacent to the stair stringer.
CONC. FLOOR SLAB CONCRETE SEALER HSS STAIR STRINGER 11" TYP. 1" TYP. 1'-0" 4" TYP. CONCRETE FILLED METAL PAN TREAD 1" S 160 Pacific Avenue, Suite 204 642 Quarry Owner, LLC 642 QUARRY ROAD PARKING STRUCTURE San Francisco, CA 94111
