This architectural detail shows a unitized aluminum curtain wall system transitioning to an aluminum screen wall at the mechanical crown level. The assembly features an eleven-sixteenths inch monolithic laminated glass type GL-4 and pre-finished aluminum elements. A type SG uplight fixture with a lens is positioned above the curtain wall head and tilted ninety degrees. The top of the assembly is aligned with Level Twenty-Nine Mechanical at elevation four-twenty feet zero inches.
08 4400 UNITIZED ALUMINUM SCREEN WALL, E-WA-05A 08 4400 11/16" [17 MM] MONOLITHIC, LAMINATED GLASS, GL-4 TYPE SG UPLIGHT 90 DEGREES TILT 08 4400 PRE-FINISHED ALUMINUM, E-MTL-01 08 4400 UNITIZED ALUMINUM CURTAIN WALL SYSTEM, E-WA-03 LEVEL 29 MECHANICAL 420' - 0" 1' - 0" LENS
