A cable tray carrying electrical cables penetrates through a one or two-hour rated gypsum board wall assembly framed with metal studs. The opening around the cable tray is tightly packed with mineral wool insulation. Firestop sealant is applied at the cable tray and gypsum board interface on both sides of the wall in accordance with UL system requirements.
EQUAL TO UL SYSTEM NUMBER W-L-4005 TYPICAL CABLE TRAY PENETRATING GYP BD WALL CABLE TRAY RE: ELEC TN101 THRU TN109 FIRESTOP SEALANT AT CABLE TRAY/ GYP BD INTERFACE ON BOTH SIDES OF WALL MINERAL WOOL INSULATION TIGHTLY- PACKED INTO OPENING 1 OR 2 HR RATED GYP BD WALL ASSEMBLY, RE: PARTITION TYPE ELEC CABLES RE: ELEC TN101 THRU TN109 METAL STUD FRAMING AROUND OPENING
