A head condition for a hollow metal door frame set within a scheduled partition. The frame anchors beneath the partition wall framing, providing a three-quarter-inch stop and a two-and-a-half-inch head profile. A three-thirty-second-inch clearance is maintained between the scheduled door and the head. The rough opening is dimensioned at one inch over the scheduled door height, with a varying overall rough opening width.
1/2" 1/2" 2 1/2" SCHEDULED DOOR LINE OF JAMB BEYOND HOLLOW METAL FRAME 3/4" SCHEDULED PARTITION SCHEDULE DOOR HEIGHT 2" VARIES 2" 1. SEE DOOR SCHEDULE FOR DOOR THICKNESS, FIRE RATING AND FINISH. 2. SEE DOOR SCHEDULE FOR FINISH HARDWARE. 3. PROVIDE 3/32" CLEARANCE BETWEEN DOOR AND HEAD. 4. ROUGH OPENING SHALL BE 1" OVER DOOR HEIGHT
