An aluminum tuning fork mullion integrates with a vision glass insulated glazing unit and a thick foil-faced mineral wool batt insulation panel to form a shadow box assembly. The system aligns with the slab edge located above the interior zone.
THICK FOIL FACED MINERAL WOOL BATT INSULATION VISION GLASS IGU SLAB EDGE, BELOW EXT. INT. 9" 2" 3" ALUMINUM TUNING FORK MULLION 3 1/2" 3" 1/2"
