A five-inch galvanized metal ladder with an integral fall arrest rail attaches to ladder support columns spaced at four feet typical. The ladder features an integrated fall protection rail and manufacturer-provided ladder supports coordinated with structural drawings. Steel grating is positioned with a seven-inch minimum clearance from the centerline.
7" MIN CLEAR 4' - 0" TYP STEEL GRATING RE: STRUCTURAL LADDER SUPPORT BY LADDER MANUFACTURER AS REQUIRED LADDER SUPPORT COLUMN RE: STRUCT S-575 INTEGRAL FALL PROTECTION RAIL 5" GALV METAL LADDER WITH INTEGRAL FALL ARREST RAIL
