Architectural · A-ZNFJ3

Stair Tread -

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A503
Discipline: Architectural

Materials

Steel

Elements

Connections / Plates Stairs

Text on the drawing

STEEL PLATE STAIRS STEEL CHANNEL STRINGER 11" SEE STAIR SECTION CLOSED RISERS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
