An exterior ceiling termination detail at the second floor perimeter incorporates a steel beam supporting a concrete slab over metal deck. An exterior insulation and finish system is applied over the framed exterior wall. Perimeter firesafing is installed at the slab edge with a metal angle. A direct-applied finish system is installed over metal ceiling joists below.
SECOND FLOOR 15'-0" EXTERIOR INTERIOR PERIMETER FIRESAFING WITH METAL ANGLE DIRECT-APPLIED FINISH SYSTEM OVER METAL CEILING JOISTS STEEL BEAM EXTERIOR INSULATION FINISH SYSTEM OVER FRAMED WALL AH12.3g 14
