A metal roof joist bears near a tilt-up concrete wall panel carrying a roof assembly with insulation and metal deck. A reinforced membrane extends across the roof surface, sealed at the cut edge with sealant and secured by fasteners and fastening plates installed per the manufacturer. Flashing extends up the face of the concrete panel, with a reinforced membrane and sealant applied at the juncture.
METAL ROOF JOIST, SEE STRUCTURAL REINFORCED MEMBRANE FASTENER AND FASTENING PLATE INSTALL PER MANUF. INSTALL PER MANUFACTURER CUT EDGE SEALANT REINFORCED MEMBRANE, SEE PLAN
