A galvanized and painted steel tube rises through the roof membrane flashing with a minimum eight-inch clearance above the roof surface. A one-quarter-inch galvanized and painted steel closure plate is welded around the perimeter at both ends. A galvanized watertight umbrella cap fits over the assembly and is secured with a stainless steel hose clamp. Joint sealant is applied to clean surfaces around the column penetration from the building below.
GALV WATER TIGHT UMBRELLA (SET 1/4" STEEL CLOSURE PLATE GALV & PAINTED - BOTH ENDS WELDED AROUND PERIMETER STEEL COLUMN FROM BUILDING BELOW, SEE STRUCTURAL SEALANT TO CLEAN SURFACE MIN. 8" STEEL TUBE, GALV & PAINTED 1/4" STEEL CLOSURE PLATE GALV & PAINTED - BOTH SIDES STAINLESS STEEL HOSE CLAMP ROOF MEMBRANE FLASHING D SCALE: 1 1/2" = 1'-0" E6 ROOF - CURB
