A structural wide-flange steel beam supports the floor assembly at level 02, aligning with a curtain wall spandrel assembly and an aluminum cover panel. A control joint is integrated near the slab edge, while storefront vision glazing extends upward. Further down the facade, a Macalloy pin connector secures a tensile structural cable via an anchor plate fastened to the building structure.
LEVEL 02 Wx BEAM, SEE STRUCTURAL 1' - 0" CW 01 SPANDREL ASSEMBLY SF 01 VISION GLAZING ALUMINUM COVER PANEL CONTROL JOINT CW 01 VISION GLAZING MACALLOY PIN CONNECTOR TENSILE STRUCTURAL CABLE SEE A8.00 SERIES ANCHOR PLATE
