A three-eighths inch diameter expansion anchor secures a bracket to the overhead structure. A twelve-gauge hanger wire connects through the bracket loop, finished with three turns at each end with a maximum three-inch spacing. A maximum one-half inch clearance is maintained at the wire loop connection.
3/8" DIA. EXPANSION ANCHOR FOR CONNECTION TO STRUCTURE SEE MAX. 3" 3 TURNS @ HANGER WIRES, TYP. @ EACH END A875 4 A874 2 A871 6 MAX. 1/2" A875 2 12 GA.WIRE
