A hollow metal frame receives sealant on both sides at the interface with the wall partition. The adjacent partition consists of boxed metal stud framing with batt insulation and gypsum board layers. A door leaf of specified thickness meets the hollow metal frame assembly.
BATT INSULATION - REFER TO SCHEDULE PARTITION - REFER TO PARTITION SCHEDULE BOXED METAL STUD FRAMING SEALANT - BOTH SIDES HM FRAME DOOR, SEE SCHEDULE NOTE: FOR OPENINGS UP TO 8'-0" WIDE 6" 2" 1/2" 1 15/16". 1 15/16".
