Precast concrete panels are set relative to a continuous footing and centerline panel and footing alignment at the building corner. A pour strip is provided at the perimeter with specific slab reinforcement consisting of two number four bars ten feet zero inches long in the concrete slab unless noted otherwise. Dimensions indicate equal spacing along the exterior wall configuration.
