A scheduled door in the open position swings clear of the corridor opening using a specialized swing-clear hinge housed within a three-and-five-eighths-inch clearance pocket. The frame integrates with scheduled partitions to maintain wall rating continuity across the opening. Partition sizes are adjusted to fit the pocket configuration with specified clearances of one-half inch and two inches.
CLEAR CORRIDOR OPENING POCKET 3 5/8" CLR SCHEDULED PARTITION SIZE TO FIT PARTITION 2" SCHEDULED DOOR IN OPEN POSITION SWING-CLEAR HINGE SCHEDULED PARTITION WALL RATING CONTINUITY 1/2" 2"
