Precast concrete stair treads feature four five-sixteenths by five-sixteenths inch deep nosing grooves extending across the full length of the stair. The treads rest on a cast-in-place concrete substructure with a six-and-one-half-inch riser height. A non-rated shadow box with quarter-inch low iron tempered glass utilizes butt joints and sits adjacent to the stair assembly. Handrail connections are recessed into the structural elements.
P0 89' - 0" A3 A411 GL-8 NON RATED SHADOW BOX WITH LOW IRON GLASS 1/4" TEMPERED CONC-3 PRECAST STAIR AND LANDING GLAZING BUTT JOINT CAST IN PLACE CONCRETE 6 1 / 2 " HANDRAILS ARE TO RECESS ALL CONNECTIONS NOSING TREAD, (4) 5/16" X 5/16" DEEP GROOVES. EXTEND ACROSS THE FULL LENGTH OF THE PRECAST STAIR
