A T-intersection between two metal stud partition walls maintains a continuous air and vapor barrier. Two layers of five-eighths-inch gypsum board carry through the intersection to ensure barrier integrity at the cold side of the wall. The assembly incorporates thermal insulation within the stud cavities and complies with Underwriters Laboratories design number U419. Refer to sheet A-61005 for additional framing and finish information.
Text on the drawing
THROUGH WALL INTERSECTION THERMAL INSULATION SEE A-61005 FOR ADDITIONAL INFORMATION FOR UL NO: U419 METAL STUD (2) LAYERS OF 5/8" GYPSUM BOARD SEE PLAN/SECT XX SEE PLAN/SECT XX CONTINUE (2) LAYERS OF 5/8" GYPSUM BOARD THROUGH WALL INTERSECTION TO PROVIDE CONTINUOUS AIR BARRIER VAPOR BARRIER AT CSH SIDE OF WALL 5/8" GYPSUM BOARD SEE PLAN/SECT XX
