The ribbon window sill, head, and jamb assembly features an aluminum mullion set against a concrete tilt-up panel with a variable thickness. The four-inch wide window frame incorporates glazing supported per elevations and specifications, with flat black paint applied to the concrete panel behind the glazing. The aluminum mullion is shimmed as required and sealed with sealant over a backer rod on each side. The concrete tilt-up panel includes a three-quarter-inch chamfer at the exterior face. An interior door sill detail is also shown adjacent, indicating a door frame, a door per the door schedule, and a three-eighths-inch undercut.
