A medium stile aluminum frame door header attaches beneath a box header framed within a scheduled partition. Continuous acoustical sealant is applied to all sides of the frame junction. The vision panel consists of three-eighths inch laminated glazing supported on a glazing setting block above the aluminum door sill.
BOX HEADER AS REQUIRED SCHEDULED PARTITION CONTINUOUS ACOUSTICAL SEALANT, ALL SIDES MEDIUM STILE ALUMINUM FRAME DOOR HEADER 3/8" LAMINATED GLAZING VISION PANEL GLAZING SETTING BLOCK ALUMINUM DOOR SILL ALUMINUM FRAME BEYOND 10" 4" 1 1/2" 3/8"
