A-ZB4N7 — Jamb

Architectural · A-ZB4N7

Jamb

Units: metric
Sheet: A363
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Connections / Plates Doors Insulation Walls Waterproofing / Flashing

Text on the drawing

CONT. SEALANT EACH SIDE PREFINISHED FORMED METAL JAMB TRIM HOLLOW METAL FRAME, PAINTED. JAMB DJ11 STEEL PLATE (REF HANGAR DOOR DRAWINGS) STEEL FRAME (REF HANGAR DOOR DRAWINGS) INSULATED-CORE METAL WALL PANELS EXTERIOR INTERIOR DOOR LEAF PER SCHEDULE

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
