This connection details a bracing splice for cold-formed steel framing members. The assembly includes flange bracing fastened with three screws at each end across the splice. Track blocking is positioned at the splice location between the studs. Gypsum board is installed where specified on the framing assembly.
GYPSUM BOARD WHERE OCCURS 3 SCREWS EACH END BRACING SPLICE FLANGE BRACING TRACK BLOCKING AT SPLICE STUD SECTION - SPLICE PLAN - SPLICE C
