A steel angle bracket attaches to the structural steel column to support a threaded rod or anchor bolt assembly extending into precast panel WA-12, referenced as 03 4510.A. A four-inch clearance exists between the column face and the panel, with a maximum eight-inch offset for the connection hardware. Refer to the elevation drawing for top-of-steel height verification.
