This interior floor detail transitions from carpet tile to tile directly beneath a door aligned with the partition above. A solid surface transition strip made of Natural Gray Corian bridges the two flooring materials. Carpet tile and tile are installed per the finish plan, maintaining a maximum one-quarter inch height tolerance across the junction. The entire assembly bears directly on the concrete slab.
DOOR, WHERE OCCURS CARPET TILE PER FINISH PLAN CONCRETE SLAB CARPET TILE / TILE TILE PER FINISH PLAN 1/4" MAX. 1 2 MAX. SOLID SURFACE TRANSITION: CORIAN "NATURAL GRAY" CARPET TILE / TILE E
