A scheduled hollow metal door frame connects to the underside of a scheduled metal stud partition. Half-inch insulation infill is placed within the metal framing where required. A scheduled door seal is installed at the door head where required above the scheduled door. The door jamb extends beyond the head assembly as scheduled.
1/2" INSUL INFILL AT METAL FRAMING WHERE REQ'D DOOR JAMB BEYOND SCHEDULED DOOR SCHEDULED HM DOOR FRAME SCHEDULED DOOR SEAL WHERE REQ'D SCHEDULED PARTITION
