This elevation details the vertical positioning for door hardware on a standard swinging door. The panic exit device touch bar is centered at a nominal height of 3'-4" above the finished floor, with the center of the crossbar located at 3'-1" nominal. A magnetic hold-open device is mounted near the top of the door, positioned 6" down from the top edge.
6" HOLD-OPEN DEVICE 3" MAGNETIC 3'-4" NOM. EXIT DEVICE CENTER OF TOUCH BAR BAR EXIT DEVICE CENTER OF CROSS 3'-1" NOM.
