This plan detail shows the geometric layout and dimension point for an exterior architectural fin attached to a curtain wall mullion relative to the edge of the concrete slab. The corner angle between the mullion centerline and the fin centerline measures 153.435 degrees. The dimension from the edge of the slab to the face of glass is 7 and 1/4 inches, with an additional 4 and 1/4 inches to the centerline of the curtain wall mullion. The exterior architectural fin, designated as FP-1, has a width of 2 and 1/2 inches with 13/32-inch offsets and a 1 and 11/16-inch web dimension. The projection distance of the fin ranges from a minimum of 3-3/8 inches to a maximum of 1'-0", with further fin information referenced on sheets A364 through A373.
4 CURTAIN WALL DIM PT OF MULLION OF FIN 4 " EDGE OF SLAB F O G 7 1 / 4 " 1 5 3 . 4 3 5 ° 4 1 / 4 " FP-1 FIN 1 / 4 " T Y P . 1 3 / 3 2 " 1 1 1 / 1 6 " 1 3 / 3 2 " 2 1 / 2 " R E : A 3 6 4 - A 3 7 3 F O R F I N I N F O R M A T I O N 3 3 / 8 " ( M I N ) - 1 ' - 0 " ( M A X )
