An electromagnetic lock and push-to-open button are provided by the door supplier. A card reader and motion sensor integrate with the system, while the remote power supply and all connecting wiring are provided by the electrical contractor. Wire gauges and types must be coordinated with the door hardware vendor.
MAG LOCK HARDWARE PUSH TO OPEN BUTTON BY DOOR SUPPLIER MOTION SENSOR BY DOOR SUPPLIER MAG LOCK BY DOOR SUPPLIER CR CARD READER BY KEYCARD SUPPLIER REMOTE POWER SUPPLY BY ELECTRICAL CONTRACTOR WIRE TO POWER SUPPLY BY ELECTRICAL CONTRACTOR WIRE BY ELECTRICAL CONTRACTOR, TYP. **COORDINATE ALL WIRE GAUGES/TYPES WITH DOOR HARDWARE VENDOR**
