A-YZC6B — Blocking Diagram

Architectural · A-YZC6B

Blocking Diagram

Scale: SCALE: 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Elements

Partitions Walls

Text on the drawing

RE: ELEVATIONS ARTWORK OR MIRROR RE: ELEVATIONS FOR LOCATION RE: SCHEDULE FOR SIZE PROVIDE BLOCKING ON THE UPPER HALF GENERAL AREA OF THE ARTWORK/MIRROR BLOCKING TO EXCEED ARTWORK/MIRROR PERIMETER BY 12" 1'-0" 1'-0" FOR ARTWORK WITH DIMENSIONS LESS THAN 48" IN ANY DIRECTION ARTWORK OR MIRROR FRAME
