An expansion joint assembly spans across a steel beam supporting a one-and-a-half-inch metal roof deck with rigid insulation and a single-ply membrane roofing system. Two-by-four pressure-treated wood nailers flank the opening, secured above the metal decking with two inches of fiberglass insulation filler below and a continuous neoprene closure spanning the gap. A foam rod, sized one-and-a-half times larger than the expansion joint width, sits in the opening with the single-ply membrane roofing extended up and over it. An isometric view shows the continuous cleat fastened at sixteen inches on center along the concrete tilt-up panel and the sloped coping sealed and fastened at twenty-four inches on center on both sides.
SEAL TPO SINGLE PLY ROOFING FASTENED @ 24" O.C. BOTH SIDES RIGID INSULATION A A SLOPED INWARD CONTINUOUS CLEAT FASTENED @ 16" O.C. SECTION AA STEEL DECK (SEE STRUCT.) CONCRETE TILT- UP PANEL FOAM ROD 1.5 TIMES LARGER THAN EXPANSION JOINT SINGLE PLY MEMBRANE ROOFING ON RIGID INSULATION ON 1 1/2" METAL ROOF DECK EXTEND ROOFING MEMBRANE UP AND OVER FOAM ROD 2x4 PRESSURE TREATED WOOD NAILERS 2" FIBERGLASS INSULATION FILLER CONT. NEOPRENE CLOSURE ACROSS OPENING STEEL BEAM, SEE FRAMING PLANS 3" METAL DECKING SEE STRUCTURAL
