Cold-formed steel framing connections for pre-engineered headers and sills frame at jamb studs. The assembly accommodates a maximum of eleven feet of wall above the header. Connection details feature pre-engineered headers and headers with inserts attached to jamb studs using clip angles and number ten sheet metal screws, varied in count for four-inch and six-inch studs. A typical sill to jamb connection features a one and a half by one and a half inch by sixteen gauge steel angle secured with number ten sheet metal screws.
PRE-ENGINEERED HEADER (SILL SIMILAR) MAX. 11'-0" WALL ABOVE HEADER PRE-ENGINEERED HEADER W/ INSERT (SILL SIMILAR) MAX. 11'-0" WALL ABOVE HEADER TYPICAL SILL TO JAMB CONNECTION (HEADER SIMILAR AT INSERT OPENING) EQ. 1/2" EQ JAMB STUD(S) PER SCHEDULE (NOT REQUIRED @ INSERT OPENING) EQ. EQ 1/2" ATTACH CLIP TO JAMB W/ 4-#10 S.M.S. @ 4" STUD, 6- #10 S.M.S. @ 6" STUD ATTACH HEADER TO CLIP W/ 4-#10 S.M.S. PRE-ENGINEERED HEADER ATTACH CLIP TO JAMB W/ 6- #10 S.M.S. @ 4" STUD, 10-#10 S.M.S. @ 6" STUD ATTACH HEADER TO CLIP W/ 4- #10 S.M.S. PRE-ENGINEERED HEADER W/ INSERT 16 GA STEEL TRACK 1 1/2" X 1 1/2" X 16GA STEEL ANGLE #10 S.M.S.
