Reinforced membrane is secured to a masonry wall or wood framed wall using bonding adhesive and various mechanical termination methods. A termination bar is fastened over the membrane with water cut-off mastic and sealant applied at the top edge. Metal counterflashing is anchored into the wall with fasteners and sealed with sealant per the manufacturer's specifications. A metal cap by others sits atop the framed parapet assembly over the reinforced membrane and bonding adhesive.
BONDING ADHESIVE REINFORCED MEMBRANE METAL CAP (BY OTHERS) MECHANICAL TERMINATION MECHANICAL TERMINATION REINFORCED MEMBRANE BONDING ADHESIVE TERMINATION BAR FASTENER CUT-OFF MASTIC SEALANT REINFORCED MEMBRANE BONDING ADHESIVE TERMINATION BAR FASTENER METAL COUNTERFLASHING INSTALL PER MANUFACTURER WATER CUT-OFF MASTIC SEALANT COUNTERFLASHING TERMINATION REINFORCED MEMBRANE BONDING ADHESIVE METAL COUNTERFLASHING, INSTALL PER MANUFACTURER SEALANT INSTALL PER MANUFACTURER FASTENER MASONRY WALL OR WOOD FRAMED WALL - SEE STRUCTURAL
