Architectural · A-YX4KB

On-Site Wall Mock-Up Panel Details

Materials

Brick Glass / Glazing EIFS / Plaster / Stucco

Elements

Walls Bracing Waterproofing / Flashing Site / Paving

About this detail

This drawing outlines the requirements for an on-site wall mock-up panel to demonstrate the construction, flashing, and sequencing of the building envelope along with exterior finishes. The panel incorporates EIFS finishes denoted as EIFS-4A and EIFS-5 with specified vertical dimensions. Field brick and accent brick colors must be confirmed with the specifications manual. Sealant color transitions between varying brick types and at glazing heads and jambs must match the adjacent brick. Temporary or permanent bracing must be provided as required.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
