An L4 x 4 x 1/4 angle brace is positioned at the deck bearing on each side at the top of the steel column and extends to the nearest joist or beam. A 1/2-inch closure plate caps the column top. The angle is welded to the steel column with a 3/16-inch fillet weld on both sides, indicated by a field weld symbol. Roof deck attachment to the angle is provided per structural drawings.
3/16 3/16 ANGLE TO COLUMN STEEL COLUMN PROVIDE TYPICAL ROOF DECK ATTACHMENT TO ANGLE, SEE STRUCTURAL 1/2" CLOSURE PLATE L4 X 4 X 1/4 ANGLE BRACE AT DECK BEARING EACH SIDE AT TOP OF COLUMN, EXTEND TO NEAREST JOIST / BEAM LADDER COLUMN AT ROOF DECK
