A roof access ship ladder is mounted adjacent to a concrete tilt-up wall, featuring sixteen risers at nine inches each for a total vertical rise of nine feet two inches. Painted one and one-half inch diameter steel pipe handrails are provided typically along the assembly. A landing is positioned at the base with a three foot six inch clearance dimension and a three foot four inch dimension below. The detail includes horizontal dimension callouts of eight inches and six feet nine and one-quarter inches.
1 C A410 D A410 1 1/2" DIA. STEEL PIPE HANDRAIL PTD. TYP. CONCRETE TILT WALL 3'-4" 8" 6'-9 1/4" 16 RISERS @ 9" EACH 9'-2" LANDING 3'-6" 2"
