Architectural · A-YVNAY

Classroom Door Sill and Window Wall Head Detail

Materials

Concrete Steel Timber / Wood Gypsum / Drywall EIFS / Plaster / Stucco Membrane / Roofing

Elements

Walls Doors Windows Curtain Walls Floors / Slabs Foundations / Footings Expansion / Control Joints Waterproofing / Flashing Insulation Anchors / Embeds Connections / Plates

Connections

Expansion / Slip Connection

About this detail

A classroom door sill and window wall head transition at the first floor level. A Sorpetaler wood door is mounted above an aluminum threshold, set upon a pressure-treated wood sill plate anchored to the concrete foundation with hot-dip galvanized sill anchors and countersunk fasteners. An ethylene propylene diene monomer sill plate gasket, flexible flashing, felt, and sealant provide moisture protection at the expansion joint. The interior floor construction incorporates Marmoleum flooring over a hydronics system, insulation, and gypsum wallboard, while stucco and a roller shade guide appear beyond.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
