A hollow metal door sits above a threshold and an L-angle wet set in sealant over a concrete slab. Compressive foam fills the back of the L-angle upstand, while a protected membrane continues up the angle leg. Below grade waterproofing components follow manufacturer recommendations at the exterior slab transition, which slopes a quarter inch per foot minimum.
