The assembly details the intersection of stair stringers and a supporting column at a lower landing. Key components include solid oak landing and tread surfaces resting on steel structural framing, specifically coped C-channel stringers and structural columns. The drawing provides a clear 3D perspective of how the timber treads interface with the steel structural framework.
Text on the drawing
COPED C-CHANNEL STRINGER LOWER LANDING STRINGER 2 1/2" SOLID OAK TREAD 2 1/2" SOLID OAK LANDING COLUMN AT LOWER LANDING PER STRUC. 15 FRAME DETAIL AT LOWER LANDING NOT TO SCALE
