Adjacent concrete wall panels feature a 1/2 inch vertical gap finished with three-quarter by three-quarter inch chamfered corners typically applied to all edges. The interior void is filled with continuous rock wool batt insulation. Each exterior face of the joint is sealed with a backer rod and joint sealant.
3/4" 1/2" 3/4" 3/4" CHAMFER ALL CORNERS, TYP. FILL GAP WITH CONTINUOUS ROCK WOOL BATT INSULATION BACKER ROD & SEALANT, EA. SIDE
