An interior sink counter and wall assembly stands at three feet two inches high. Five-eighths-inch Type X gypsum board forms the vertical wall and horizontal counter substrate. A laminate finish labeled PL-4 covers the counter surface and backsplashing. Quartz surface component QSC-1 and vinyl wall protection VWP-1 are integrated into the assembly, while the floor base is installed as scheduled.
